| ویژگی | مقدار |
|---|---|
| Hardware Accelerated 25 GE SFP28 / 10 GE SFP+ Slots | 4 |
| Hardware Accelerated 10 GE SFP+ / GE SFP Slots | 4 |
| Hardware Accelerated GE SFP Slots | 16 |
| GE Management Port | 1 |
| USB Ports (Client / Server) | 2 |
| Console Port | 1 |
| Onboard Storage | 2x 480GB |
| Trusted Platform Module (TPM) | Yes |
| Included Transceivers | 2x SFP SX |
| IPS Throughput | 38Gbps |
| NGFW Throughput | 29Gbps |
| Threat Protection Throughput | 26Gbps |
| IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) | 164 / 163 / 145 Gbps |
| IPv6 Firewall Throughput (1518 / 512 / 86 byte, UDP) | 164 / 163 / 145 Gbps |
| Firewall Latency (64 byte UDP packets) | 3.78μs |
| Firewall Throughput (Packets Per Second) | 217.5Mpps |
| Concurrent Sessions (TCP) | 16Million |
| New Sessions/Second (TCP) | 700,000 |
| Firewall Policies | 10,000 |
| IPsec VPN Throughput (512 byte) | 55Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 2,000 |
| Client-to-Gateway IPsec VPN Tunnels | 50,000 |
| SSL-VPN Throughput | 8Gbps |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) | 10,000 |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 14Gbps |
| SSL Inspection CPS (IPS, avg. HTTPS) | 13,000 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 1.6Million |
| Application Control Throughput (HTTP 64K) | 50Gbps |
| Virtual Domains (Default / Maximum) | 10 / 50 |
| Maximum Number of FortiSwitches Supported | 96 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 1024 / 512 |
| Maximum Number of FortiTokens | 5,000 |
| High Availability Configurations | Active-Active, Active-Passive, Clustering |
| Dimensions | Height x Width x Length 1.5 x 17.0 x 13.5 (in) 44.45 x 432 x 342 (mm) |
| Weight (maximum) | 7.72lbs (3.5kg) |
| Form Factor (supports EIA/non‑EIA standards) | Rack Mount, 1RU |
| AC Power Supply | 100–240VAC, 50/60 Hz |
| AC Current (Maximum) | 6A@100VAC |
| Power Consumption (Average / Maximum) | 240W / 295W |
| Heat Dissipation | 1006BTU/h |
| Redundant Power Supplies (Hot Swappable) | Yes (Default dual non-swappable AC PSU for 1+1 Redundancy) |
| Operating Temperature | 32°F to 113°F (0°C to 45°C) |
| Storage Temperature | -31°F to 158°F (-35°C to 70°C) |
| Humidity | 10%–90% non-condensing |
| Noise Level | 59dBA |
| Forced Airflow | Side and Front to Back |
| Operating Altitude | Up to 10,000 ft (3048 m) |
| Compliance | FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB |
| Certifications | USGv6/IPv6 |
این مدل از فایروال فورتیگیت از نظر عملکرد و پورتها تقریباً با FortiGate FG-700G که قبلاً توضیح داده شد، یکسان است، اما یک تفاوت کلیدی و مهم دارد که آن را برای ذخیرهسازی محلی لاگها مناسب میسازد.
تنها تفاوت عمده بین این دو مدل در ظرفیت ذخیرهسازی داخلی (Onboard Storage) آنهاست:
| ویژگی | FortiGate 700G | FortiGate 701G |
| ذخیرهسازی داخلی | ندارد (فقط برای سیستم عامل) | دارای دو (2) هارد SSD داخلی |
| ظرفیت SSD داخلی | – | 2SSD x 480GB |
اضافه شدن دو SSD با ظرفیت کلی 960GB در مدل FG-701G، مزایای زیر را برای سازمانها فراهم میکند:
تمام معیارهای عملکردی (Throughput) در مدل 701G دقیقاً مشابه مدل 700G باقی میماند، زیرا هر دو از یک ساختار پردازنده اصلی (شامل NP7 و CP10 برای شتابدهی) استفاده میکنند:
مدل FortiGate FG-701G برای محیطهای سازمانی بزرگ و دیتاسنترها که نیاز به عملکرد بالا (پورتهای 25GE) همراه با قابلیتهای گزارشگیری محلی قوی و ذخیره طولانیمدت لاگهای ترافیک و امنیتی دارند، انتخاب بهتری است.
