سری BIG-IP i15000 بالاترین عملکرد دستگاه‌ها را ارائه می‌دهد که برای ارائه دهندگان خدمات و شرکت های بزرگ طراحی شده است. این مجموعه عملکرد بالا برای امنیت و خدمات در فرم فکتور 2RU را فراهم می‌کند. i15000 با اتصالات همزمان 300M لایه 4، امکان ادغام چندین سرویس را در یک دستگاه از جمله بهینه سازی TCP/IP، فرمان ترافیک ، فایروال ، DDoS ، CGNAT و DNS فراهم می کند. این سری دارای بالاترین توان لایه 4 موجود در یک دستگاه است و از توان 320 / 160G از L4 / L7 تا 10M L7 RPS پشتیبانی می کند. این مجموعه دارای چهار برابر TurboFlex FPGA است.
| Platform | i15600 | i15800 |
|---|---|---|
Intelligent Traffic Processing |
||
| L7 requests per second | 5M | 10M |
| L4 connections per second | 2.4M | 4.2M |
| L4 HTTP requests per second | 28M | 35M |
| Maximum L4 concurrent connections | 300M | 300M |
| Throughput | 320Gbps/160Gbps L4/L7 | 320Gbps/160Gbps L4/L7 |
Hardware Offload |
||
| SSL/TLS | ECC† : 60K TPS (ECDSA P-256) RSA: 80K TPS (2K Keys) 50Gbps bulk encryption* |
ECC† : 100K TPS (ECDSA P-256) RSA: 160K TPS (2K Keys) 50Gbps bulk encryption* |
| FIPS SSL | N/A | N/A |
| Hardware Compression | N/A | 60Gbps |
| Hardware DDoS Protection | 140M SYN cookies per second | 210M SYN cookies per second |
| TurboFlex Performance Profiles | N/A | Tier 3 (4xBW) |
Software Offload |
||
| Software Compression | 30Gbps | N/A |
| Software Architecture | 64-bit TMOS | 64-bit TMOS |
| On-Demand Upgradable | Yes | N/A |
| Virtualization (Maximum Number of vCMP Guests) | N/A | 56 |
Hardware Specifications |
||
| Processor | Two 14-Core Intel Xeon processors (total 56 hyperthreaded logical processor cores) | Two 14-Core Intel Xeon processors (total 56 hyperthreaded logical processor cores) |
| Memory | 512GB DDR4 | 512GB DDR4 |
| Hard Drive | 1×1.6TB Enterprise Class SSD | 1×1.6TB Enterprise Class SSD |
| Gigabit Ethernet CU Ports | N/A | N/A |
| Gigabit Fiber Ports (SFP) | N/A | N/A |
| 10 Gigabit Fiber Ports (SFP+) | N/A | N/A |
| 40 Gigabit Fiber Ports (QSFP+) | 8SR4/LR4 (sold separately) (QSFP+ optical breakout cable assemblies available to convert to 10G ports) | 8SR4/LR4 (sold separately) (QSFP+ optical breakout cable assemblies available to convert to 10G ports) |
| 100 Gigabit Fiber Ports (QSFP28) | 4SR4/LR4 (sold separately) QSFP28 | 4SR4/LR4 (sold separately) QSFP28 |
Power Specifications |
||
| Power Supply | 2x1500W Platinum AC PSU | 2x1500W Platinum AC PSU |
| Typical Consumption | 885W(dual power supply, 110V input)** | 885W(dual power supply, 110V input)** |
| Input Voltage | 100–240VAC +/- 10% auto switching, 50/60hz | 100–240VAC +/- 10% auto switching, 50/60hz |
| Typical Heat Output | 3020BTU/hour (dual power supply, 110V input)** | 3020BTU/hour (dual power supply, 110V input)** |
Physical Specifications |
||
| Dimensions | 3.45”(8.76 cm) H x 17.9” (45.47 cm) W x 30.2” (76.71 cm) D 2U industry standard rack-mount chassis |
3.45”(8.76 cm) H x 17.9” (45.47 cm) W x 30.2” (76.71 cm) D 2U industry standard rack-mount chassis |
| Weight | 76lbs.(34.47kg) (Dual power supply) | 76lbs.(34.47kg) (Dual power supply) |
Environment Specifications |
||
| Operating Temperature | 32°to104°F(0° to 40° C) | 32°to104°F(0° to 40° C) |
| Operational Relative Humidity | 5%to85% at 40º C | 5%to85% at 40º C |
Safety and Certifications |
||
| Safety Agency Approval | ANSI/UL 60950-1-2014 CSA 60950-1-07, including A1:2011+A2:2014 IEC 60950-1:2005, A1:2009+A2:2013 EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013 |
ANSI/UL 60950-1-2014 CSA 60950-1-07, including A1:2011+A2:2014 IEC 60950-1:2005, A1:2009+A2:2013 EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013 |
| Certifications/ Susceptibility Standards | ETSI EN 300 386 V1.6.1 (2012) EN 55032:2012 Class A: EN 61000-3-2:2014 EN 61000-3-3:2013: EN 55024:2010 FCC Class A (Part 15), IC Class A, VCCI Class A |
ETSI EN 300 386 V1.6.1 (2012) EN 55032:2012 Class A: EN 61000-3-2:2014 EN 61000-3-3:2013: EN 55024:2010 FCC Class A (Part 15), IC Class A, VCCI Class A |
Notes: Performance-related numbers are based on local traffic management services only. Only optics provided by F5 are supported.
* Maximum throughput.
** Please refer to the Platform Guide: i15000 Series for the latest power ratings for your specific configurations (number of PS, highline input voltage, DC, etc.).
† ECDHE-ECDSA-AES128-SHA256 cipher string tested.
| Dimensions | 3.45”(8.76cm)Hx17.9”(45.47cm)W x30.2”(76.71cm)D |
|---|---|
| Weight | 34.47kg (Dual power supply) |
| Processor | Two 14-Core Intel Xeon processors (total 56 hyperthreaded logical processor cores) |
| Communication interfaces | 4x100Gigabit Fiber Ports (QSFP28), 8×40 Gigabit Fiber Ports (QSFP+) |
| Storage drive capacity | 1×1.6TB Enterprise Class SSD |
| RAM | 512GB DDR4 |
| Power Supplies | 2x1500W Platinum AC PSU |
| Throughput | 320Gbps/160Gbps L4/L7 |
| Typical Consumption | 885W(dual power supply, 110V input)** |
| Input Voltage | 100-240VAC+/-10% auto switching.50/60hz |
| Typical Heat Output | 3020BTU/hour (dual power supply, 110V input)** |
| Operating Relative Humidity | 5%to85% at 40° C |
| Operating temperature | 32°to104°F (0° to 40°C) |
