پلتفرم میان رده سری BIG-IP i4000 ADC که در دو مدل i4600/i4800 طراحی و تولید شده است، عملکردی استثنایی را ارائه می دهد که اکثر نیازهای برنامههای کاربردی سازمانی کوچک و متوسط و خدمات امنیتی را برآورده می کند. بعد از اینکه مشتری محترم، مدل موردنیاز سازمان خود را مشخص نمود، براساس توان محاسباتی مدل انتخابی، ماژولها و لایسنسهای مختلف تعیین میشود.
i4800 توان دوبرابر لایه 4 ، 2.8 برابر اتصالات همزمان لایه 4 و 2.2 برابر SSL TPS را نسبت به مدل های مشابه قبلی فراهم می کند.
SPECIFICATIONS
|
i4800 |
i4600
|
Intelligent Traffic Processing |
L7 requests per second: 1.1M L4 connections per second: 450K L4 HTTP requests per second: 2M Maximum L4 concurrent connections: 28M Throughput: 20Gbps L4/L7 |
L7 requests per second: 650K L4 connections per second: 250K L4 HTTP requests per second: 1M Maximum L4 concurrent connections: 28M Throughput: 20Gbps L4/L7 |
Hardware Offload SSL/TLS |
ECC†: 10K TPS (ECDSA P-256) RSA: 20K TPS (2K keys) 15Gbps bulk encryption* |
ECC†: 6.5K TPS (ECDSA P-256) RSA: 10K TPS (2K keys) 10Gbps bulk encryption* |
FIPS SSL |
N/A | N/A |
Hardware Compression |
10Gbps | N/A |
Hardware DDoS Protection |
N/A | N/A |
TurboFlex Performance Profiles |
Tier 2 | N/A |
Software Compression |
N/A | 6Gbps |
Software Architecture |
64-bit TMOS | 64-bit TMOS |
On-Demand Upgradable |
N/A | Yes |
Virtualization (Maximum
|
N/A | N/A |
Processor |
One 4-Core Intel Xeon processor (total 8 hyperthreaded logical processor cores) |
One 4-Core Intel Xeon processor (total 8 hyperthreaded logical processor cores) |
Memory |
32GB DDR4 | 32GB DDR4 |
Hard Drive |
1TB Enterprise Class HDD | 1TB Enterprise Class HDD |
Gigabit Ethernet CU Ports |
Optional SFP | Optional SFP |
Gigabit Fiber Ports (SFP) |
8SX or LX (sold separately) | 8SX or LX (sold separately) |
10Gigabit Fiber Ports (SFP+) |
4SR/LR (sold separately); optional 10G copper direct attach | 4SR/LR (sold separately); optional 10G copper d |
40Gigabit Fiber Ports (QSFP+) |
N/A | N/A |
Power Supply |
1x250W Platinum AC PSU (Additional PSU optional, 2x 650W DC PSU Option) |
1x250W Platinum AC PSU (Additional PSU optio 2x 650W DC PSU Option) |
Typical Consumption |
130W(single power supply, 110V input)** | 130W(single power supply, 110V input)** |
Input Voltage |
100-240VAC +/- 10% auto switching, 50/60hz | 100-240VAC +/- 10% auto switching, 50/60hz |
Typical Heat Output |
445BTU/hour(single power supply, 110V input)** | 445 BTU/hour(single power supply, 110V input)* |
Dimensions |
1.72”(4.37cm)H x17.4”(44.2cm)W x22.5”(57.15cm)D 1U industry standard rack-mount chassis |
1.72”(4.37 cm)H x17.4”(44.2 cm)W x22.5”(57.1 1U industry standard rack-mount chassis |
Weight |
20lbs. (9.07 kg) (single power supply) | 20lbs. (9.07 kg) (single power supply) |
Operating Temperature |
32°F to 104°F | 32°F to 104°F |
Operational Relative Humidity |
5%to 85% at 40º C | 5%to 85% at 40º C |
Safety Agency Approval |
ANSI/UL 60950-1-2014 CSA 60950-1-07, including A1:2011+A2:2014 IEC 60950-1:2005, A1:2009+A2:2013 EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013 |
ANSI/UL 60950-1-2014 CSA 60950-1-07, including A1:2011+A2:2014 IEC 60950-1:2005, A1:2009+A2:2013 EN 60950-1:2006+A11:2009+A1:2010+A12:2011+ |
Certifications/
|
ETSI EN 300 386 V1.6.1 (2012) EN 55032:2012 Class A; EN 61000-3-2:2014 EN 61000-3-3:2013; EN 55024:2010 FCC Class A (Part 15), IC Class A, VCCI Class A |
ETSI EN 300 386 V1.6.1 (2012) EN 55032:2012 Class A; EN 61000-3-2:2014 EN 61000-3-3:2013; EN 55024:2010 FCC Class A (Part 15), IC Class A, VCCI Class A |
Notes: Performance-related numbers are based on local trafc management services only. Only optics provided by F5 are supported.
*Maximum throughput.
**Please refer to the Platform Guide: i4000 Series for the latest power ratings for your specifc confgurations (SSL, SSD, highline input voltage, DC, etc.).
†ECDHE-ECDSA-AES128-SHA256 cipher string tested.
