توضیحات
فایروال فورتیگیت نسل بعدی FG-600E فاقد حافظه داخلی است، این درحالی است که فایروال فورتیگیت مدل FG-601E دارای دو اسلات ماژول حافظه داخلی 240 گیگابایتی از نوع SSD است.
فورتی گیت (Fortigate 601E (FG-601E
| FortiGate 601E | ||
|---|---|---|
Hardware Specifications |
||
| GE SFP Slots | 8 | |
| 10GE SFP Slots | 2 | |
| GE RJ45 Ports | 8 | |
| GE RJ45 Management Ports | 2 | |
| USB Ports | 2 | |
| Console (RJ45) | 1 | |
| Onboard Storage | 2x240GB SSD | |
| Included Transceivers |
2xSFP(SX 1GE) | |
System Performance — Enterprise Traffic Mix |
||
| IPS Throughput | 10Gbps | |
| NGFW Throughput | 9.5Gbps | |
| Threat Protection Throughput | 7Gbps | |
System Performance |
||
| IPv4 Firewall Throughput (1518/512/64byte UDP packets) | 36/36/27Gbps | |
| IPv6 Firewall Throughput (1518/512/64byte UDP packets) | 36/36/27Gbps | |
| Firewall Latency (64byte UDP packets) | 1.54μs | |
| Firewall Throughput (Packets Per Second) | 40.5Mpps | |
| Concurrent Sessions (TCP) | 8Million | |
| New Sessions/Second (TCP) | 450,000 | |
| Firewall Policies | 10,000 | |
| IPsec VPN Throughput (512byte packets) | 20Gbps | |
| Gateway-to-Gateway IPsec VPN Tunnels | 2,000 | |
| Client-to-Gateway IPsec VPN Tunnels | 50,000 | |
| SSL-VPN Throughput | 7Gbps | |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) | 10,000 | |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 8Gbps | |
| SSL Inspection CPS (IPS, avg. HTTPS) | 5,500 | |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 800,000 | |
| Application Control Throughput (HTTP 64K) | 15Gbps | |
| CAPWAP Throughput (1444 byte, UDP) | 18Gbps | |
| Virtual Domains (Default / Maximum) | 10/10 | |
| Maximum Number of FortiSwitches Supported | 96 | |
| Maximum Number of FortiAPs (Total / Tunnel Mode) | 1,024/512 | |
| Maximum Number of FortiTokens | 5,000 | |
| High Availability Configurations | Active/Active, Active/Passive, Clustering | |
Dimensions |
||
| Height xWidth x Length (inches) | 1.75x17x15 | |
| Height x Width x Length (mm) | 44.45x432x380 | |
| Weight | 16.6lbs(7.5kg) | |
| Form Factor | Rack Mount, 1RU | |
Operating Environment and Certifications |
||
| Power Consumption (Average / Maximum) | 129W/244W | |
| Power Input | 100–240V AC, 50–60Hz | |
| Current (Maximum) | 6A@100V | |
| Heat Dissipation | 832BTU/h | |
| Redundant Power Supplies (Hot Swappable) | Optional | |
| Operating Temperature | 32–104°F(0–40°C) | |
| Storage Temperature | -31–158°F(-35–70°C) | |
| Humidity | 10–90%non-condensing | |
| noise Level | 59dBA | |
| Operating Altitude | Up to 9,843ft (3,000m) | |
| Airflow | Side and Front to Back | |
| Compliance | FCC Part 15 Class A, CE, RCM, VCCI, UL/cUL, CB | |
| Certifications | ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN; USGv6/IPv6 | |
