Fortinet FortiAP 831F
حداکثر مصرف برق:
- 33W
تعداد رادیو:
- 3 1BLE
تماس بگیرید
توضیح کوتاه
حداکثر مصرف برق:
- 33W
تعداد رادیو:
- 3 1BLE
رابط:
- 1×100/1000/2500Base-T RJ45
- 1×10/100/1000Base-T RJ45
- 1xType 3.0 USB, 1xRS-232 RJ45 Serial Port
حداکثر مصرف برق:
- 33W
تعداد رادیو:
- 3 1BLE
تعداد آنتن:
- 4 2.4GHz band WiFi 8 5GHz band WiFi I Dual band Scanning 1 2.4GHz band BLE
| Hardware Type |
Indoor AP |
|---|---|
| Number of Radios |
3 1BLE |
| Number of Antennas |
4 2.4GHz band WiFi 8 5GHz band WiFi I Dual band Scanning 1 2.4GHz band BLE |
| Antenna Type and Peak Gain |
PIFA: 4.0dBi for 2.4GHz band WiFi antennas 6.0dBi for 5.0GHz band WiFi antennas 4.0dBi for dual band Scanning radio antenna 4.5dBi for 2.4GHz band BLE antenna |
| Frequency Bands (GHz) |
2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725, 5.725–5.850 |
| Radio 1 Capabilities |
Frequency Band: 2.4GHz Channel width: 20/40MHz Modulation: BPSK, QPSK, QAM64 MIMO chains: 4x4service |
| Radio 2 Capabilities |
Frequency Band: 5.0GHz Channel width: 20/40/80/80 80/160MHz Modulation: BPSK, QPSK, QAM64, QAM256, and QAM1024 Mimo chains: 8x8service in mode 1or 4×4 4×4 service in mode 2 |
| Radio 3 Capabilities |
Frequency bands: 2.4GHz and 5.0GHz MIMO Chains: 1x1Frequency Scanning |
| Maximum Data Rate |
Radio 1: up to 1147.5Mbps Radio 2: up to 4.804Gbps in 8x8MIMO and in 4×4 4x4MIMO modes |
| Bluetooth Low Energy Radio |
Bluetooth scanning and iBeacon advertisement @10dBm max TX power |
| Interfaces |
1×100/1000/2500 Base-T RJ45 1×10/100/1000 Base-T RJ45 1xType 3.0 USB, 1xRS-232 RJ45 Serial Port |
| Power over Ethernet (PoE) |
2×802.3at/bt/30W Passive PoE in (Full function) 1×802.3at PoE in (USB3.1 disabled) |
| Simultaneous SSIDs |
Up to 24 |
| EAP Type(s) |
EAP-TLS, EAP-TTLS/MSCHAPv2, EAPv0/EAPMSCHAPv2,PEAPv1/EAP-GTC, EAP-SIM, EAP-AKA, EAP-FAST |
| User/Device Authentication |
WPA™, WPA2™, and WPA3™ with 802.1x or Preshared key, WEP, Web Captive Portal, MAC blacklist & whitelist |
| Maximum Tx Power (Conducted) |
Radio 1: 2.4GHz 27dBm / 500mW (4chains combined) Radio 2: 5GHz 25.5dBm / 354mW (4chains combined) Radio 3: NA |
| Kensington Lock |
Yes |
| IEEE Standards |
802.11a, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h, 802.11i,802.11j, 802.11k, 802.11n, 802.11r, 802.11v, 802.11ac, 802.11ax (Wi-Fi 6), 802.1Q, 802.1X, 802.3ad, 802.3af, 802.3at, 802.3az, 802.3bz |
| SSID Types Supported |
Local-Bridge, Tunnel, and Mesh |
| Per Radio Client Capacity |
Up to 512 clients per radio (Radio1 and Radio2) |
| LED Off Mode |
Yes |
| Rogue Scan radio modes |
Dedicated |
| WIPS / WIDS radio modes |
Dedicated |
| Packet Sniffer Mode |
Yes |
| Spectrum Analyzer |
Yes |
| Dimensions |
9.05×89.05×2.15inches (230x230x55mm) |
| Weight |
2.25lbs (1.02kg) |
| Package (shipping) Weight |
4.2lbs (1.9kg) |
| Mounting Options |
Ceiling, T-Rail, and Wall |
| Included Accessories |
Mount kit for Ceiling, T-Rail, and Wall |
| power-supplies |
PoE type 802.3af/at/bt Supports dual redundant 802.3af/at DC Power: 12V DC / 3 Amps |
| Power Consumption (Maximum) |
33W |
| PSE functionality |
No |
| POE Mode Single 5G |
DC/2at –> Full Mode ; Radios will be in (8×8, 4×4) & USB Enabled 1at/2af –> High Mode ; Radios will be in (8×8, 4×4) & USB Disabled 1af –> Low Mode ; Radios will be [2×2, 2×2], Tx Power 10 dBm & USB Disabled |
| POE Mode Dual 5G |
DC/2at –> Full Mode ; Radios will be in [4×4, 4×4, 4×4] & USB Enabled 1at/2af –> High Mode ; Radios will be in [4×4, 4×4, 4×4] & USB Disabled 1af –> Low Mode ; Radios will be [2×2, 2×2, 2×2], Tx Power 10 dBm & USB Disabled |
| Humidity |
5 -90%non condensing |
| Operating / Storage Temperature |
32–122°F (0–50°C) / -22–-158°F (-30–70°C) |
| Directives |
Low Voltage Directive • RoHS |
| UL2043 Plenum Material |
No |
| Mean Time Between Failures |
> 10 Years |
| Surge Protection Built In |
Yes |
| WiFi Alliance Certified |
Yes |
| DFS |
CE |
