Fortinet FortiAP U24JEV
رابط:
- 4×10/100/1000Base-T RJ45 Ports (1×802.3at PoE (PD), 1×802.3af PoE (PSE), 2xNon-PoE Ports), 1Pass-through in RJ45, 1Pass-through out RJ45
حداکثر مصرف برق:
- 24W (Depends on PoE connected and USB power consumed)
تماس بگیرید
توضیح کوتاه
رابط:
- 4×10/100/1000Base-T RJ45 Ports (1×802.3at PoE (PD), 1×802.3af PoE (PSE), 2xNon-PoE Ports), 1Pass-through in RJ45, 1Pass-through out RJ45
حداکثر مصرف برق:
- 24W (Depends on PoE connected and USB power consumed)
رابط:
- 4×10/100/1000Base-T RJ45 Ports (1×802.3at PoE (PD), 1×802.3af PoE (PSE), 2xNon-PoE Ports), 1Pass-through in RJ45, 1Pass-through out RJ45
حداکثر مصرف برق:
- 24W (Depends on PoE connected and USB power consumed)
تعداد رادیو:
- 1(can operate as 2) 1BT/BLE
تعداد آنتن:
-
2Internal 1BT/BLE Internal
| Hardware Type |
Wall Plate AP |
|---|---|
| Number of Radios |
1(can operate as 2) 1BT/BLE |
| Number of Antennas |
2Internal 1BT/BLE Internal |
| Antenna Type and Peak Gain |
Patch: 3dBi for 2.4GHz, 4dBi for 5GHz |
| Frequency Bands (GHz) |
2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725, 5.725–5.850 |
| Radio 1 Capabilities |
2.4GHz b/g/n (2×2:2 stream) 20/40MHz (64 QAM) or 5GHz a/n/ac (2×2:2 stream) 20/40/80MHz (256 QAM) or 2.4GHz b/g/n (1×1:1 stream) 20/40MHz (64 QAM) & 5GHz a/n/ac (1×1:1 stream) 20/40/80MHz (256 QAM) |
| Radio 2 Capabilities |
ـ |
| Maximum Data Rate |
up to 867Mbps |
| Bluetooth Low Energy (BT/BLE) Radio |
Bluetooth scanning and iBeacon advertisement @4dBm max TX power |
| Interfaces |
4×10/100/1000 Base-T RJ45 Ports (1×802.3at PoE (PD), 1x 802.3af PoE (PSE), 2x Non-PoE Ports), 1Pass-through in RJ45, 1Pass-through out RJ45 |
| Power over Ethernet (PoE) |
802.3af (max PSE output of 4W) or 802.3at (full 802.3af PSE output) |
| Simultaneous SSIDs |
Up to 16 (14 if background scanning enabled) |
| EAP Type(s) |
EAP-TLS, EAP-TTLS/MSCHAPv2, EAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC EAP-SIM, EAP-AKA, EAP-FAST |
| User/Device Authentication |
WPA and WPA2 with 802.1x or Preshared key, WEP, Web Captive Portal, MAC blacklist & whitelist |
| Maximum Tx Power |
2.4GHz: 23dBm / 200mW (2chains combined) 5GHz: 21dBm / 126mW (2chains combined) |
| Kensington Lock |
No |
| IEEE Standards |
802.11a, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h, 802.11i, 802.11j, 802.11k, 802.11n, 802.11v, 802.11ac, 802.1X, 802.3af, 802.3at, 802.3az, 802.3ad |
| SSID Types Supported |
Local-Bridge, Tunnel |
| Per Radio Client Capacity |
Up to 128 |
| LED Off Mode |
Yes |
| Packet Sniffer Mode |
Yes |
| Spectrum Analyzer |
Yes |
| Dimensions |
6.1×3.7×1.2inches(155 x 95 x 31mm) |
| Weight |
0.569lbs (0.258kg) |
| Package (shipping) Weight |
1.34lbs (0.606kg) |
| Mounting Options |
Wall plate or desk stand |
| Included Accessories |
Mounting kit for wall plate |
| Power Supply |
SP-FAPU24-PA-XX, GPI-115, or GPI-130 |
| Power Consumption (Max.) |
24W (Depends on PoE connected and USB power consumed) |
| Humidity |
10% to 90%non-condensing |
| Operating Temperature |
32 to 122°F (0–50°C) |
| Storage Temperature |
'-22 to 104˚F (-30 to 70˚C) |
| Directives |
RoHS |
| UL2043 Plenum Material |
No |
| Mean Time Between Failures |
>30Years |
| IP Rating |
— |
| Surge Protection Built In |
— |
| Hit-less PoE Failover |
No |
| WiFi Alliance Certified |
Yes |
| DFS |
CE |
